LA6063
Small size, light operation, with a touch of buttons and high durability
PDFApplications:
This product can be used in many fields. Please explain the application fields when the client inquires about the product, so that our sales can provide more detailed product specification information.
LA6063 series
| P/N | Picture | Outline size | Type | Force | Travel | PIN | LED color | Button type | Laser sign | |
| CLA606301D127 |  |
6.0*6.0*9.40 | DIP | 150±50gf | 0.25±0.10mm | 4 | - | - |  |
|
| CLA606301D107 |  |
6.0*6.0*9.40 | DIP | 150±50gf | 0.25±0.10mm | 4 | - | |
||
| CLA606301D130 | |
6.0*6.0*9.40 | DIP | 200±50gf | 0.25±0.10mm | 4 | GREEN | - | - | |
| CLA606301D132 | |
6.0*6.0*9.40 | DIP | 150±50gf | 0.25±0.10mm | 4 | - | - | - | |
| CLA606301D87 |  |
6.0*6.0*9.40 | momentary | 220±30gf | 0.25±0.1mm | 4 | white | |
||
| CLA606301D11 | |
6.0*6.0*9.40 | momentary | 150±50gf | 0.25±0.1mm | 6 | blue | |
||
| CLA606301D02 | |
6.0*6.0*8.45 | momentary | 150±50gf | 0.25±0.1mm | 6 | white | |
